10KV Three-phase Epoxy Resin Cast Dry-type Distribution Transformer（SCB11 Series）

10KV Three-phase Epoxy Resin Cast Dry-type Distribution Transformer（SCB11 Series ）

Product Description：

The 10kV Three-phase Epoxy Resin Cast Dry-type Distribution Transformer (SCB11 Series) is designed for modern distribution networks requiring high reliability, low loss, and enhanced fire safety. The transformer adopts vacuum epoxy resin casting technology, ensuring excellent insulation, strong moisture resistance, and stable temperature performance. With its low noise level and minimal maintenance requirements, the SCB11 series is widely used in residential areas, commercial buildings, industrial plants, substations, and indoor electrical rooms.

Product Advantages：

1. High Efficiency & Energy Saving:Optimized design to reduce no-load and load losses.

2. Stable Performance:Strong structure, excellent short-circuit resistance, and efficient heat dissipation.

3. Maintenance-Free:No oil change or regular component replacement required.

Application Scenarios：

1. Urban & Residential Distribution Systems：Installed in indoor distribution rooms to supply stable power to residential buildings, elevators, lighting systems, and community load centers.

2. Commercial Buildings and Public Facilities：Used in malls, hospitals, office towers, and transport hubs where fire safety and low noise requirements are strict.

3. Industrial Plants and Manufacturing Workshops：Provides stable voltage for production lines, CNC equipment, motors, and industrial control systems in dusty or humid workshops.

4. Indoor Substations and Compact Power Stations：Built into compact substations or modular power units, enabling safe indoor distribution in dense urban areas.

5. Tunnels, Underground Facilities, and Fire-sensitive Areas：Used in subway tunnels, underground parking structures, and high-risk zones due to its non-flammable insulation and smokeless failure features.

Safety & Quality Assurance：

The SCB11 series complies with ASTM standards. Each unit undergoes temperature rise testing, partial discharge testing, routine electrical tests, and resin curing inspection to ensure long-term reliability.

FAQ：

Q1: What capacity range is available?

A1: Standard 30–2500 kVA, customizable upon request.

Q2: Can it be installed outdoors?

A2: Outdoor protective enclosures are optional.

Q3: Does it require regular oil maintenance?

A3: No. It is a completely dry-type, oil-free system.
