Composite Suspension Polymer Insulator
24kV tension composite insulator are manufactured conforming to international standards and specifications. We are the leading Composite Silicone Insulator Manufacturer and Supplier in Zhejiang.
Features:
1.Ratings:12~500kV.
2. Application: for lines supporting and insulation of power transmission & distribution system.
Parameter
Technical data of 24KV tension composite insulator
Type | Rated voltage (kV) | Rated mechanical tension load (kN) | Structure height (mm) | Min nominal creepage distance (mm) | 1min power frequency wet withstand voltage (kV) | Full wave lightning impulse withstand voltage peak value (kV) |
FXB1-24 / 70YB | 24 | 70 | 460 | 650 | 75 | 180 |
