CU-AL terminals

Terminals refer to wiring terminals, also known as wiring terminals, which can be classified into single hole, double hole, socket, hook, etc. In terms of materials, they can be silver plated copper, zinc plated copper, copper, aluminum, iron, etc. Their main function is to transmit electrical signals or conduct electricity.

Availability:

Quantity:



Inquire Add to Basket

CU-AL terminals electrical terminal copper lug quick connect terminal

Product Description

Copper aluminum terminals

Terminals refer to wiring terminals, also known as wiring terminals, which can be classified into single hole, double hole, socket, hook, etc. In terms of materials, they can be silver plated copper, zinc plated copper, copper, aluminum, iron, etc. Their main function is to transmit electrical signals or conduct electricity.

Features:

1.DTL series of copper-aluminum wiring terminals are suitable for transition connection of circular aluminum wires, hemicycle-sector aluminum wires, power supply cables in the distribution equipment.

2.The technology of friction welding is wonderfully adopted,Therefore they have distinguishing features of strong weld intensity,good nature in electrification,galvanic corrosion resistant and long service life.

Our advantages：

1. Using exclusive thickened materials

2. After special processing, it is more durable, corrosion-resistant, and antioxidant

3. Firmly installed, suitable for various occasions

Parameter

Item No.	Cable spec(mm²)	Dimensions(mm)
Item No.	Cable spec(mm²)	ø	D	d	L	L1	B
DTL10	10	8.5	10	6	68	28	16
DTL16	16	8.5	11	6	70	32	16
DTL25	25	8.5	12	7	75	34	18
DTL35	35	10.5	14	8.5	85	40	20.5
DTL50	50	10.5	16	9.8	90	42	23
DTL70	70	12.5	18	11.5	100	47	26
DTL95	95	12.5	21	13.5	110	50	28
DTL120	120	14.5	23	15	120	53	30
DTL150	150	14.5	25	16.5	125	55	34
DTL185	185	17	28	18.5	136	58	37
DTL240	240	17	30	21	148	60	40
DTL300	300	21	34	23.5	165	65	50
DTL400	400	21	38	27	170	70	50
DTL500	500D	21	47	29	225	75	60
