Porcelain insulators are insulators made of electrical ceramics as insulation components. Electrical ceramics are baked from quartz, feldspar, and clay as raw materials. The surface of porcelain insulators is usually covered with porcelain glaze to improve their mechanical strength, prevent water infiltration, and increase surface smoothness.
Zinc oxide lightning arrester is a lightning arrester with good protective performance. Utilizing the excellent nonlinear volt-ampere characteristics of zinc oxide, the current flowing through the lightning arrester at normal operating voltage is extremely small (microampere or milliampere level); When overvoltage occurs, the resistance drops sharply, releasing the energy of overvoltage to achieve protection.
Suspension clamp is a hardware device that suspends the grounding wire to the suspension insulator string or hardware string.The body is made of UV resistant,glass fiber reinforced synthetic material.The insulated neutral messager is secured by the notched tightening lever.It is used for suspending the low voltage A.B.C.(Aerial bundled conductors)
Preformed Guy Grips is a common metal product mainly used in industries such as electrical equipment, communication equipment, and mechanical equipment. According to their different materials, structures, and uses, Preformed Guy Grips can be classified into various types.
Fuse Link in the circuit system mainly serve as overload protection. If the fuse Link is correctly placed in the circuit, it will fuse Link and cut off the current when the current abnormally rises to a certain height and heat, protecting the safe operation of the circuit
Terminals refer to wiring terminals, also known as wiring terminals, which can be classified into single hole, double hole, socket, hook, etc. In terms of materials, they can be silver plated copper, zinc plated copper, copper, aluminum, iron, etc. Their main function is to transmit electrical signals or conduct electricity.
Bolted copper lugs are widely used for secure cable-to-equipment connections, offering high conductivity and excellent mechanical strength for easy installation and maintenance.
Zinc oxide surge arrester is a lightning protection device with superior protection performance, light weight, pollution resistance and stable performance. It mainly uses the good non-linear volt-ampere characteristics of zinc oxide to make the current flowing through the surge arrester at normal working voltage very small (microamp or milliampere level); when the overvoltage acts, the resistance drops sharply, venting the overvoltage Energy to achieve the effect of protection. The difference between this kind of lightning arrester and the traditional lightning arrester is that it has no discharge gap, and uses the non-linear characteristics of zinc oxide to discharge and break.
Zinc oxide lightning arrester is a lightning arrester with good protective performance. By utilizing the excellent nonlinear volt ampere characteristics of zinc oxide, the current flowing through the lightning arrester at normal operating voltage is minimized; When overvoltage occurs, the resistance drops sharply, releasing the energy of the overvoltage to achieve protection.
The galvanized single steel wires or stranded steel wires are suitable for cores of ACSR to improve its tensile strength. And they can also be used in the aerial transmission line as the line material of ground connection to avoid the lightning strike. Messenger Wire, Overhead Ground or Static Wire, Guy Wire.
Low-voltage ABC cable, designed for overhead power lines and room entrance wires with a rated AC pressure of 1kv and below. It has less installation, maintenance, and operating costs, which can achieve greater economic loss and provide higher security and reliability.
☆ Some of the load Centers are made out of high quality Electro-galvanized steel sheet of up to 1.2-1.5mm thickness ☆ Matt-Finish polyester powder coated paint ☆ Knockouts provided on all sides of the enclosure. ☆ Accept plug-in circuit breakers. ☆ Suitable for single-Phase,Three-wire,120/240Vac,rated current to 125A ☆ Wider enclosure offers ease or wiring and move heat dissipation. ☆ Flush and Surface mounted designs ☆ Knockouts for cable entry are provided on Top,Bottom of the Enclosure.
☆Made out of high quality steel sheet of up to 0.8-1.2mm thickness. ☆Matt-Finish polyester powder coated paint. ☆Knockouts provided on all sides of the enclosure. ☆Accept Square D type plug-in circuit breakere. ☆Suitable for AC 60Hz, rated voltage to 240V, rated current to 100A. ☆Suitable for single-phase, three-wire,rated current to 100A, sevice voltage to 120/240Vac ☆Wider enclosure offers ease or wiring and move heat dissipation. ☆Flush and Surface mounted designs. ☆Knockouts for cable entry are orovided on Top, Bottom of the Enclosure.
Made out of high quality electro-galvanized steel sheet of up to 0.9-1.5mm thickness.Matt-finsh polyester power coated paint. Knockouts provided provided on all sides of the enclosure. Accept GE's Q line circuit breakers,including GE's exclusive 1/2"THOPs. Suitable for single-phase,three-wire,120/240Vac,rated cyrrent to 225A. Convertible to main breaker. Wider enclousure offers ease or wiring and move heat dissipation. Flush and surface mounted designs.Knockouts for cable entry are entry are provided on top,bottom of the enclosure.
☆Made out of high quality steel sheet of up to 0.8-1.2mm thickness. ☆Matt-Finish polyester powder coated paint. ☆Knockouts provided on all sides of the enclosure. ☆Accept Square D type plug-in circuit breakere. ☆Suitable for AC 60Hz, rated voltage to 240V, rated current to 100A. ☆Suitable for single-phase, three-wire,rated current to 100A, sevice voltage to 120/240Vac ☆Wider enclosure offers ease or wiring and move heat dissipation. ☆Flush and Surface mounted designs. ☆Knockouts for cable entry are orovided on Top, Bottom of the Enclosure.
☆Made out of high quality steelsheet of up to 0.8-1.2mm thickness ☆Matt-Finish polyester powdercoated paint. ☆Knockouts provided on all sides of the enclosure. ☆Accept GE type 1"THQL breakers. ☆Suitable for single-phase, three-wire,rated current to 100A, sevice voltage to 120/240Vac ☆Wider enclosure offers ease or wiring and move heat dissipation. ☆Flush and surface mounted designs. ☆Knockouts for cable entry are provided on Top,Bottom of the Enclosure.
☆Made out of high quality steelsheet of up to 0.8-1.2mm thickness ☆Matt-Finish polyester powdercoated paint. ☆Knockouts provided on all sides of the enclosure. ☆Accept GE type 1"THQL breakers. ☆Suitable for single-phase, three-wire,rated current to 100A, sevice voltage to 120/240Vac ☆Wider enclosure offers ease or wiring and move heat dissipation. ☆Flush and surface mounted designs. ☆Knockouts for cable entry are provided on Top,Bottom of the Enclosure.
☆Designed for residential or light commercial application where duty is not severe 60℃ and 75℃ conductor rating; ☆Spring-reinforced fuse cips are suitable for class H,K or R fuses-assure reliable contact and cool operation. ☆Direct-drive,quick-make,quick-break machanism ensures long life and positive ON/OFF indication. ☆Suitable for using as service entrance equipment when installed in accordance with nation electracal code. ☆Removable interior and ample qutter space make installation and wiring quick and easy. ☆Straight-through wiring and multiple knockouts speed installation. ☆Padlocking device allows for added security.
