The Preformed Guy Grip is a helical-type tension hardware designed for securing guy wires, stay wires, and supporting strands on utility poles and tower structures. Manufactured from high-strength galvanized steel or aluminum-clad steel, the grip provides excellent mechanical holding power without causing damage to the cable. Its preformed spiral design ensures fast installation, uniform stress distribution, and long-term durability under harsh outdoor environments.
Features
1.Single person operation, convenient installation
2.High strength
3.Good relaxation performance
Product advantages
1.High holding strength with uniform stress distribution
2. No sharp edges — prevents damage to the guy wire
3.Corrosion-resistant materials ensure long service life
4.Easy and fast installation without special tools
5.Excellent vibration resistance for overhead lines
Our advantages
1.Professional responsibility
2. Good quality and affordable price
3. Good after-sales service
4. One on one dedicated person to answer your questions
5. Tight packaging
6.Flash shipment
Application scenarios
1.Pole Line Guying and Anchoring：Used to terminate guy wires on wooden, concrete, or steel poles to ensure pole stability.
2. Transmission & Distribution Line Support：Provides secure dead-end connection for supporting strands in overhead power lines.
3. Communication Tower Guying：Ideal for telecom towers, microwave towers, and radio masts requiring high-strength tension hardware.
4. Antenna & Utility Structure Stabilization：Used for anchoring antennas and utility structures exposed to wind load.
5. Railway & Railway Signal Poles：Ensures the stability of signal poles and lines in railway systems.
Parameter
Catalogue Number | Conductors GBT117199/83LGJ/LGJF | Length | Pieces | |
Section(mm2) | O.D(mm) | |||
TNL-16/3 | 16/3 | 5.55 | 444 | 3 |
TNL-25/4 | 25/4 | 6.96 | 546 | 3 |
TNL-35/8 | 35/8 | 8.16 | 622 | 3 |
TNL-50/8 | 50/8 | 9.60 | 685 | 3 |
TNL-70/10 | 70/10 | 11.4 | 736 | 3 |
TNL-95/15 | 95/15 | 13.61 | 876 | 4 |
TNL-95/20 | 95/20 | 13.87 | 876 | 4 |
TNL-120/7 | 120/7 | 14.5 | 876 | 4 |
TNL-120/20 | 120/20 | 15.07 | 889 | 4 |
TNL-120/25 | 120/25 | 15.74 | 889 | 4 |
TNL-150/8 | 150/8 | 16.00 | 889 | 4 |
TNL-150/20 | 150/20 | 16.67 | 1016 | 5 |
TNL-150/25 | 150/25 | 17.10 | 1016 | 5 |
TNL-150/35 | 150/35 | 17.5 | 1016 | 5 |
TNL-185/10 | 185/10 | 18.00 | 1016 | 5 |
TNL-185/25 | 185/25 | 18.88 | 1155 | 6 |
TNL-185/30 | 185/30 | 18.90 | 1155 | 6 |
TNL-185/45 | 185/45 | 19.00 | 1155 | 6 |
TNL-210/10 | 210/10 | 19.60 | 1155 | 6 |
TNL-210/25 | 210/25 | 19.98 | 1155 | 6 |
TNL-210/35 | 210/35 | 20.38 | 1155 | 6 |
TNL-210/50 | 210/50 | 20.86 | 1155 | 6 |
TNL-240/30 | 240/30 | 21.60 | 1270 | 8 |
TNL-240/40 | 240/40 | 21.66 | 1270 | 8 |
TNL-300/15 | 300/15 | 23.04 | 1270 | 8 |
TNL-300/20 | 300/20 | 23.43 | 1270 | 8 |
TNL-300/25 | 300/25 | 19.76 | 1442 | 10 |
TNL-300/40 | 300/40 | 26.94 | 1442 | 10 |
TNL-300/50 | 300/50 | 24.26 | 1442 | 10 |
FAQ
Q1: What size of guy grip should I choose?
A1: Select the model that matches the strand diameter. Contact us for a size chart.
Q2: Can the grip be reused?
A2: No. Preformed guy grips are designed for one-time installation.
Q3: Does it damage the guy wire?
A3: No. The smooth helical design holds the wire without causing abrasion.
Q4: What materials are available?
A4: Galvanized steel and aluminum-clad steel are available.
