The LXY Series U160BL Glass Insulator is a high-strength toughened glass suspension insulator designed for high-voltage overhead transmission lines. This U160BL glass insulator provides excellent mechanical strength and stable electrical insulation performance, making it suitable for long-span transmission lines and heavy conductor loads. Its transparent glass structure allows easy visual inspection, helping utilities quickly identify damage and maintain system reliability.
(1) Compared with porcelain, it has a very high dielectric strength;
(2) High electrical resistivity;
(3) Compared with porcelain insulators, it has higher tensile strength;
(4) Due to its transparent nature, it will not be heated in sunlight like porcelain;
(5) The impurities and bubbles inside the glass insulator body are easily detected due to their transparency;
(6) The service life of glass is very long because its mechanical and electrical properties are not affected by aging;
(7) Glass is cheaper than porcelain.
High mechanical strength for heavy conductor loads
Excellent electrical insulation performance
Transparent glass for easy visual inspection
Strong resistance to aging and environmental effects
Low maintenance requirements and long service life
Stable performance under high voltage conditions
Type | IEC Class | D mm | Hmm | Creepage Distance mm | Coupling Size | Min.Mechanical Failing Load KN | Min.Impact Failing Load KN | Min.Lighting Impulse Withstand Volt .KV | Power Frequency Withstand Volt.KV | Approx.Net Weight kg | |
Min.Wet One Minute | Min.Puncture volt. | ||||||||||
LXY-160 | U160BL | 280 | 146 | 380 | 20 | 160 | 1017 | 105 | 42 | 110 | 6.1 |
High voltage overhead transmission lines
Long-span transmission line sections
Suspension insulator strings for power grids
Utility transmission and distribution networks
• Install the LXY Series U160BL glass insulator as part of a suspension insulator string.
• Connect the insulator using standard ball-and-socket fittings.
• Ensure proper string length based on system voltage requirements.
• Conduct regular visual inspections to detect damage or breakage.
Manufactured from high-quality toughened glass materials
Strict testing on mechanical load and electrical performance
Consistent quality control throughout production
Designed to meet utility transmission standards
Reliable long-term outdoor performance
Q1: What is the main application of the U160BL glass insulator?
A1: It is used as a suspension insulator for high voltage overhead transmission lines.
Q2: What advantages does glass insulation provide?
A2: Glass insulators offer high mechanical strength and allow easy visual inspection.
Q3: Is the U160BL glass insulator suitable for harsh environments?
A3: Yes, it performs well under pollution, humidity, and temperature variations.
Q4: How is the insulator inspected during operation?
A4: Visual inspection can easily detect cracks or breakage due to its transparent glass.
Q5: Does the glass insulator require frequent maintenance?
A5: No, it requires minimal maintenance over its long service life.
