The 10–15kV Polyethylene Cable Spacer is designed to maintain proper spacing and alignment of conductors in overhead power distribution systems. Made from high-strength polyethylene material, this high voltage polyethylene cable spacer provides excellent insulation performance, mechanical strength, and resistance to environmental aging.
The 10-15kV polyethylene cable spacer for overhead lines helps prevent conductor clashing, reduces vibration, and improves overall line stability. It is widely used in medium-voltage power distribution networks where safe conductor separation and long-term reliability are required.
1.Unbreakable and light weight
2.Easiest handing and transportation
3.Water repelling surface
4.Long service life
5.Non-toxic,non-standing and recyclable
Excellent insulation performance for 10–15kV systems
High-strength polyethylene material
Lightweight design for easy installation
Prevents conductor contact and phase short-circuit
Reduces vibration and improves line stability
Resistant to UV, moisture, and weather aging
Long service life in outdoor environments
Suitable for various overhead cable configurations
10–15kV overhead power distribution lines
Medium voltage insulated conductor systems
Urban and rural overhead power networks
Areas with strong wind or line vibration
Utility power infrastructure projects
• Select the appropriate 10–15kV polyethylene cable spacer according to conductor size and phase spacing.
• Position the spacer between adjacent conductors at the designed interval.
• Secure the conductors into the spacer grooves or clamps.
• Ensure proper alignment and spacing after installation.
• Perform routine inspection during line maintenance.
| Rated Voltage of system Line to Line up to | 15kV | |
| Electrical Characteristics | Under Rain Frequency | 34kV |
| Dry Atmosphere | 110kV | |
| Mechanical Characteristics | Ultimate mechanical strength | 4500N |
| Main Dimensions(mm) | D | 180 |
| H | 300 | |
| h | 145 | |
| C1 | 170.7 | |
| Weight(kg) | 0.5 | |
| Qty(pcs)/Ctn | 11 | |
| Qty(pcs)/20FT | 4620 | |
High-quality polyethylene raw materials
Strict insulation and mechanical strength testing
UV resistance and aging performance inspection
Dimensional accuracy and installation fit checks
Final quality inspection before delivery
Q1: What is a 10–15kV polyethylene cable spacer used for?
A1: It is used to maintain safe spacing and alignment of conductors in overhead lines.
Q2: Is this cable spacer suitable for outdoor use?
A2: Yes, it is designed for long-term outdoor exposure with UV resistance.
Q3: Can this spacer be used on insulated conductors?
A3: Yes, it is suitable for insulated overhead conductors.
Q4: Does the spacer help reduce conductor vibration?
A4: Yes, it helps stabilize conductors and reduce vibration.
Q5: Can the 10–15kV polyethylene cable spacer be customized?
A5: Yes, specifications can be customized according to project requirements.
