LXY series U80BL Glass Insulator

The LXY Series U80BL Glass Insulator is a high-strength toughened glass disc insulator designed for overhead power transmission and distribution lines. This U80BL glass insulator features excellent mechanical strength, stable electrical performance, and superior self-cleaning capability. Manufactured using advanced toughened glass technology, the LXY series glass insulator provides reliable insulation and long service life, making it a preferred solution for utility-grade transmission line applications.

Product Advantages

• High mechanical strength suitable for heavy conductor loads

• Toughened glass material ensures excellent impact resistance

• Stable electrical insulation performance

• Excellent self-cleaning ability in outdoor environments

• Visible condition allows easy inspection of defects

• Good resistance to pollution and aging

• Low maintenance requirement over long service life

• Compatible with standard insulator strings and fittings

• Utility-grade quality for transmission and distribution systems

• Reliable performance under varying climate conditions

Features

(1) Compared with porcelain, it has a very high dielectric strength;

(2) High electrical resistivity;

(3) Compared with porcelain insulators, it has higher tensile strength;

(4) Due to its transparent nature, it will not be heated in sunlight like porcelain;

(5) The impurities and bubbles inside the glass insulator body are easily detected due to their transparency;

(6) The service life of glass is very long because its mechanical and electrical properties are not affected by aging; (8) Glass is cheaper than porcelain.

Applications & How to Apply

• Overhead transmission lines

• Overhead distribution lines

• Insulator strings for high-voltage towers and poles

• Power grids in polluted or coastal areas

• Urban and rural power infrastructure projects

How to Apply :

• Select the LXY series U80BL glass insulator according to system voltage and mechanical load requirements.

• Assemble the glass insulators into strings using standard fittings and hardware.

• Install the insulator string onto transmission towers or distribution poles.

• Attach conductors securely to the insulator string to ensure proper insulation and mechanical support.

• Conduct routine visual inspection to monitor operating condition during service.

Parameter

Quality Assurance

• Manufactured in accordance with IEC and utility industry standards

• Strict control of glass tempering and mechanical strength

• 100% inspection for visual defects and dimensional accuracy

• Electrical and mechanical performance tested before delivery

• Stable quality suitable for long-term outdoor operation

FAQ

Q1: What is the U80BL glass insulator used for?

A1: It is used for insulation and mechanical support in overhead transmission and distribution lines.

Q2: Why choose glass insulators instead of porcelain?

A2: Glass insulators offer visible defect detection, strong self-cleaning ability, and stable performance.

Q3: Is the LXY series U80BL suitable for polluted areas?

A3: Yes, it performs well in polluted and coastal environments.

Q4: Does it require frequent maintenance?

A4: No, only routine visual inspection is required.

Q5: Can it be used in both transmission and distribution systems?

A5: Yes, it is suitable for both transmission and distribution applications.
