The REACON 25kV High Voltage Fuse Cutout is designed to provide reliable overcurrent and short-circuit protection for outdoor electrical distribution systems. This 25kV fuse cutout isolates faulty sections quickly, protecting transformers and overhead lines while ensuring safe operation and easy maintenance. With durable insulation and weather-resistant construction, the REACON 25kV high voltage fuse cutout is widely used in utility-grade power distribution networks.
Designed for 25kV high voltage distribution systems
Reliable fault isolation protects transformers and lines
Visible open position improves operational safety
High-quality insulation ensures stable electrical performance
Weather-resistant design for outdoor environments
Compatible with standard high voltage fuse links
Strong mechanical structure for long-term service
Easy installation and replacement of fuse links
Utility-grade quality for distribution networks
Reduced maintenance and downtime
25kV overhead distribution lines
Pole-mounted transformer protection
Outdoor utility power distribution networks
Rural and urban electrification projects
Feeder line overcurrent protection
• Mount the REACON 25kV high voltage fuse cutout on a pole or crossarm using standard mounting hardware.
• Connect the upper terminal to the incoming high voltage line and the lower terminal to the transformer or outgoing line.
• Install an appropriate fuse link based on the rated current requirement.
• Use an insulated operating stick to open or close the fuse cutout safely.
• After fault clearance, replace the fuse link and restore power.
Manufactured according to IEC / ANSI high voltage standards
100% electrical and mechanical performance testing
Strict inspection of insulation and fittings
Corrosion resistance verified for outdoor use
Consistent quality for long-term utility operation
| Rated voltage(KV) | Rated current(A) | Rated interrupting current(KA) | Lightning impulse withstand voltage to ground (BIL KV) | Minimum power frequency withstand dry voltage to ground (KV) | Minimum creepage distance(mm) |
| 25 | 100/200 | 12 | 150 | 65 | 470 |
Q1: What voltage system is this fuse cutout designed for?
A1: It is specifically designed for 25kV distribution systems.
Q2: Can it be used outdoors long-term?
A2: Yes, it is designed for continuous outdoor operation.
Q3: Is it suitable for transformer protection?
A3: Yes, it is commonly used for pole-mounted transformer protection.
Q4: Is the open position visible after operation?
A4: Yes, the visible drop-out position improves safety.
Q5: Does it support standard fuse links?
A5: Yes, it is compatible with standard high voltage fuse links.
