Al-Cu Bimetal PG Clamp

Product Description

The CAPG-C Aluminum Copper Bimetallic PG Clamp is specifically designed for secure electrical connection between aluminum and copper conductors in overhead power line systems. This bimetallic PG clamp for overhead line ensures stable electrical conductivity while preventing galvanic corrosion between dissimilar metals.

Featuring a special bimetallic structure and anti-corrosion treatment, the CAPG-C aluminum copper PG clamp provides long-term reliability in outdoor environments. It is widely used in power distribution networks where aluminum and copper conductors must be connected safely and efficiently.

1.Aluminum alloy clamp body with copper insert

2.Designed for Al-Cu conductor connections

3.Galvanic corrosion-resistant construction

4.Strong mechanical grip with stainless steel bolts

5.Suitable for overhead power lines and grounding systems

Product Advantages

1. Bimetallic design for aluminum-to-copper connection

2. Anti-corrosion treatment prevents galvanic corrosion

3. Low contact resistance and high conductivity

4. Strong mechanical clamping force

5. Suitable for overhead power line applications

6. Easy installation without conductor cutting

7. Reliable performance in outdoor environments

8. Widely used in power distribution systems

Applications & How to Apply

1. Overhead power distribution lines

2. Aluminum conductor to copper conductor connections

3. Utility pole-mounted power systems

4. Power line branching and tapping connections

5. Outdoor electrical bonding applications

How to Apply ：

• Select the correct CAPG-C aluminum copper bimetallic PG clamp according to conductor size.

• Place the aluminum and copper conductors into the parallel grooves.

• Tighten the bolts evenly to ensure firm mechanical and electrical contact.

• Check contact surfaces to confirm proper alignment and pressure.

• Perform final inspection before energizing the overhead line.

Quality Assurance

1. High-quality aluminum and copper materials

2. Precision machining for accurate groove dimensions

3. Anti-corrosion surface treatment

4. Electrical conductivity and mechanical strength testing

5. Strict final inspection before shipment


Our advantages

1.High Load Capacity: Rigorously tested to provide reliable support for heavy-duty equipment in demanding environments.

2. Corrosion Resistance: The specialized aluminum alloy construction offers effective protection against moisture and chemical corrosion.

3. Eco-Friendly & Energy Saving: Lightweight design minimizes transportation and installation energy consumption, contributing to a greener solution.

4.Cost-Effective: Offers excellent cost-performance ratio, making it ideal for large-scale custom orders and installations.

5.Wide Application: Designed to cater to both indoor and outdoor mounting scenarios, meeting diverse industry requirements.

Parameter

FAQ

Q1: What is a bimetallic PG clamp used for?

A1: It is used to connect aluminum conductors to copper conductors in overhead lines.

Q2: Does this PG clamp prevent corrosion?

A2: Yes, the bimetallic design and surface treatment prevent galvanic corrosion.

Q3: Is the CAPG-C PG clamp suitable for outdoor use?

A3: Yes, it is designed for long-term outdoor applications.

Q4: Does installation require special tools?

A4: Only standard tightening tools are required.

Q5: Can it be used in power distribution systems?

A5: Yes, it is widely used in utility power distribution networks.
