The ANSI C29 F Neck Pin Type Modified Polyethylene Insulator is designed for overhead power distribution systems requiring reliable insulation and mechanical support. Manufactured in accordance with ANSI C29 standards, this F Neck pin type insulator is made from high-quality modified polyethylene material, offering excellent electrical insulation, mechanical strength, and weather resistance.
This ANSI C29 F Neck pin type polyethylene insulator is widely used on distribution poles to support conductors while maintaining safe electrical clearance. Its lightweight structure, combined with durable insulation performance, makes it a cost-effective and reliable solution for modern overhead distribution networks.
1.Ratings:12~500kV.
2. Application: for lines supporting and insulation of power transmission & distribution system.
Compliant with ANSI C29 standard
High-quality modified polyethylene material
Excellent electrical insulation performance
Strong mechanical load capacity
Lightweight and easy to handle
Outstanding weather and UV resistance
Resistant to moisture and contamination
Long service life with low maintenance
Type | Rated voltage (kV) | Rated mechanical tension load (kN) | Structure height (mm) | Min nominal creepage distance (mm) | 1min power frequency wet withstand voltage (kV) | Full wave lightning impulse withstand voltage peak value (kV) |
FXB1-24 / 70YB | 24 | 70 | 460 | 650 | 75 | 180 |
Overhead distribution power lines
Utility pole-mounted conductor support
Low and medium voltage distribution networks
Urban and rural power distribution projects
Replacement of traditional porcelain pin insulators
• Select the appropriate ANSI C29 F Neck pin type insulator according to line voltage and conductor size.
• Mount the insulator securely onto a standard insulator pin on the utility pole.
• Ensure proper alignment to maintain correct conductor position.
• Place the conductor in the insulator groove and secure it as required.
• Inspect installation to confirm electrical clearance and mechanical stability.
Manufactured under strict quality control system
Raw materials tested for insulation and durability
Mechanical and electrical performance tested before delivery
Compliance with ANSI C29 specifications
Consistent product performance for long-term use
Q1: What standard does this insulator comply with?
A1: It complies with ANSI C29 standard.
Q2: What material is used for this pin type insulator?
A2: It is made from high-quality modified polyethylene.
Q3: Is this insulator suitable for outdoor use?
A3: Yes, it is designed for outdoor overhead power lines.
Q4: Can it replace porcelain pin type insulators?
A4: Yes, it is commonly used as a replacement due to lighter weight and better weather resistance.
Q5: What voltage levels is it suitable for?
A5: It is suitable for low to medium voltage distribution systems.
