The Twisted Preformed Grip for Guying Applications is a high-strength, helical-type dead-end device designed for securing guy wires on utility poles, communication towers, transmission lines, and other tension-bearing structures. Manufactured from galvanized or alloy steel, it provides superior tensile performance, excellent corrosion resistance, and a vibration-resistant structure. The preformed design ensures perfect matching with the guy strand, offering reliable, slip-free holding without damaging the wire surface. It requires no special tools, allowing fast, safe, and error-free installation even for inexperienced workers.
Product advantages
1.High tensile strength and stable mechanical performance
2. Hot-dip galvanized surface for long-term corrosion resistance
3. Precise helical design prevents slipping and wire damage
4. Simple, tool-free installation
5. Strong grip with uniform stress distribution
6.Long service life suitable for harsh outdoor environments
Our advantages
1.Professional responsibility
2. Good quality and affordable price
3. Good after-sales service
4. One on one dedicated person to answer your questions
5. Tight packaging
6.Flash shipment
Application Scenarios
The Twisted Preformed Grip for Guying Applications is commonly used in situations where guy wires must maintain long-term stability under continuous tension. It is suitable for power distribution poles that require lateral support, preventing tilting caused by wind loads or uneven line pulling. In communication tower construction, the grip helps secure multi-directional guy strands, ensuring tower alignment during strong wind events or heavy equipment installation. It is also utilized in the reinforcement of substation steel structures, where guy wires are arranged to stabilize auxiliary frames and prevent structural vibration. For rural broadband deployment, the grip can be used to anchor support strands for aerial cables, improving line safety over long spans. In areas with coastal environments or high humidity, the galvanized version performs well for corrosion-resistant anchoring of ADSS, OPGW, or galvanized steel strand systems.
Parameter
Catalogue Number | Conductors GBT117199/83LGJ/LGJF | Length | Pieces | |
Section(mm2) | O.D(mm) | |||
TNL-16/3 | 16/3 | 5.55 | 444 | 3 |
TNL-25/4 | 25/4 | 6.96 | 546 | 3 |
TNL-35/8 | 35/8 | 8.16 | 622 | 3 |
TNL-50/8 | 50/8 | 9.60 | 685 | 3 |
TNL-70/10 | 70/10 | 11.4 | 736 | 3 |
TNL-95/15 | 95/15 | 13.61 | 876 | 4 |
TNL-95/20 | 95/20 | 13.87 | 876 | 4 |
TNL-120/7 | 120/7 | 14.5 | 876 | 4 |
TNL-120/20 | 120/20 | 15.07 | 889 | 4 |
TNL-120/25 | 120/25 | 15.74 | 889 | 4 |
TNL-150/8 | 150/8 | 16.00 | 889 | 4 |
TNL-150/20 | 150/20 | 16.67 | 1016 | 5 |
TNL-150/25 | 150/25 | 17.10 | 1016 | 5 |
TNL-150/35 | 150/35 | 17.5 | 1016 | 5 |
TNL-185/10 | 185/10 | 18.00 | 1016 | 5 |
TNL-185/25 | 185/25 | 18.88 | 1155 | 6 |
TNL-185/30 | 185/30 | 18.90 | 1155 | 6 |
TNL-185/45 | 185/45 | 19.00 | 1155 | 6 |
TNL-210/10 | 210/10 | 19.60 | 1155 | 6 |
TNL-210/25 | 210/25 | 19.98 | 1155 | 6 |
TNL-210/35 | 210/35 | 20.38 | 1155 | 6 |
TNL-210/50 | 210/50 | 20.86 | 1155 | 6 |
TNL-240/30 | 240/30 | 21.60 | 1270 | 8 |
TNL-240/40 | 240/40 | 21.66 | 1270 | 8 |
TNL-300/15 | 300/15 | 23.04 | 1270 | 8 |
TNL-300/20 | 300/20 | 23.43 | 1270 | 8 |
TNL-300/25 | 300/25 | 19.76 | 1442 | 10 |
TNL-300/40 | 300/40 | 26.94 | 1442 | 10 |
TNL-300/50 | 300/50 | 24.26 | 1442 | 10 |
Frequently Asked Questions：
Q1: Is the preformed wire difficult to install?
A1: Very easy, can be installed manually without special tools.
Q2: Is it compatible with various conductors?
A2: Yes, it fits a wide range of standard conductor sizes.
Q3: Will it damage the conductor?
A3: No, its design ensures even pressure and surface protection.
